SPM3012T-1R0M
Manufacturer:
TDK Corporation
Mfr.Part #:
SPM3012T-1R0M
Datasheet:
Description:
Fixed Inductors SMD,3.20mmL×3.00mmW×1.20mmH SMD/SMT 1 µH 20 % 2.8 A 65 mΩ
| Parameter | Value |
|---|---|
| Tolerance | 20 % |
| Height - Seated (Max) | 1.2 mm |
| Length | 3.2 mm |
| Width | 2.9972 mm |
| Termination | SMD/SMT |
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -40 °C |
| Case Code (Metric) | 3012 |
| Composition(Kit Type) | Wirewound |
| Height | 1.2 mm |
| Depth | 3.1 mm |
| REACH SVHC | No SVHC |
| Current Rating | 2.8 A |
| DC Resistance (DCR) | 65 mΩ |
| Test Frequency | 100 kHz |
| Military Standard | Not |
| Shielding | Shielded |
| Inductance | 1 µH |
| Core Material | Metal |
| RMS Current (Irms) | 2.8 A |
| inductance tolerance | 20 % |
| Max DC Current | 5.4 A |
| Saturation Current | 3.4 A |
| Schedule B | 8504500000 |
| RoHS | Compliant |
| Packaging | Reel |
| Type | Wirewound |
Stock: 1626
Distributors
pcbx
pcbxUnit Price$0.65066
Ext.Price$0.65066
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.65066 | $0.65066 |
| 10 | $0.53740 | $5.37400 |
| 25 | $0.50340 | $12.58500 |
| 50 | $0.47155 | $23.57750 |
| 100 | $0.44170 | $44.17000 |
| 300 | $0.41385 | $124.15500 |
| 500 | $0.38776 | $193.88000 |
| 1000 | $0.36331 | $363.31000 |
